Product Specifications
- Model / Series
- SV24-1500PS
- Product Dimensions
- 295 × 242 × 98 mm
- System Voltages
- 12 V / 24 V automatic identification
- Rated Charge Current
- 60 A
- Maximum PV Open-Circuit Voltage
- 50 V
- Conversion Efficiency
- >82%
SV24-1500PS combines 1500 W sine wave AC output and up to 60 A solar charging for 12 V or 24 V battery systems. Its integrated controller and inverter enclosure offers distributors and off-grid installers a single unit for battery charging and AC power conversion. The maximum PV open-circuit voltage is 50 V. Contact GERIXI to confirm the supplied configuration and available branding options.
Key Features
- 1500 W continuous sine wave output, with a catalog tolerance of ±10%.
- Integrated solar charging with a maximum charging current of 60 A.
- Automatic identification of 12 V and 24 V battery systems.
- Digital operating display, front controls and dual cooling fans.
- 220 V AC output and 5 V / 2.4 A USB output.
- High/low voltage, overload and short-circuit alarm functions.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | SV24-1500PS |
| Continuous output power | 1500 W ±10% |
| Output waveform | Sine wave |
| Battery system voltage | 12 V / 24 V, automatic identification |
| Maximum solar charging current | 60 A |
| Maximum PV open-circuit voltage | 50 V |
| AC output voltage | 220 V ±10% |
| AC output frequency | 50 Hz |
| USB output | 5 V / 2.4 A |
| Full-load efficiency | >82% |
| Product dimensions | 295 × 242 × 98 mm |
| Net weight | 3190 g |
Applications
For off-grid residential supply, rural distribution projects and compatible small-business backup loads. Importers can specify this model where both solar battery charging and 1500 W-class AC conversion are required. Check continuous load demand and equipment starting requirements before selecting an installation.
Battery & PV Compatibility
Confirm the battery chemistry and charging settings for the supplied 12 V or 24 V system. The array open-circuit voltage must remain within 50 V, including cold-weather voltage rise. The catalog recommends panel operating voltages of 15–23 V for 12 V charging and 30–46 V for 24 V charging; confirm array power and current with GERIXI before ordering. Connect the battery first and follow the supplied installation instructions.
OEM & Order Information
Send GERIXI your order quantity, destination market and logo or packaging requirements. The sales team can confirm available customization, MOQ, pricing and documentation for the ordered configuration.
FAQ
What should distributors provide for a branding enquiry?
Share logo artwork, packaging language and expected quantities so GERIXI can confirm customization options and order conditions.
Which documents should importers request?
Request compliance documents identifying the supplied SV24-1500PS configuration and check their suitability for the destination market before ordering.
How can installers confirm warranty terms?
Provide the intended battery system, load profile and installation conditions to obtain the applicable written warranty terms from GERIXI.
